Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―166― HD30 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
F16.19
AO1 terminal output
function selection
0: Reserved
1: Output frequency (0－
max. output frequency)
2: Reference frquency (0－
max. output frequency)
3: Motor speed (0－
maximum output frequency
corresponding to speed)
4: Output current (0－twice
motor’s rated current)
5: Output current (0－twice
motor’s rated current)
6－9: Reserved
10: Output torque (0－3
times motor’s rated torque)
11: Output voltage (0－1.2
times inverter’s rated
voltage)
12: Bus voltage (0－2.2
times inverter’s rated
voltage)
13: Output power (0－twice
motor’s rated power)
14: AI1 input (0－10V)
15: AI2 input (-10－10V / 0－
20mA)
16: AI3 input (-10－10V / 0－
20mA)
17: AI4 input (-10－10V / 0－
20mA)
18: Output frequency (- 1
times－1 times maximum
output frequency)
19: Reference frequency (- 1
times－1 times maximum
output frequency)
1 1 ○
F16.20
AO2 terminal output
function selection
0 1 ○
F16.21
High-speed pulse
output function
selection
0 1 ○
F16.22
Analogue output AO1
bias
-100.0－100.0% 0.0% 0.1% ○
F16.23
Analogue output AO1
gain
0.0－200.0% 100.0% 0.1% ○
F16.24
Analogue output AO2
bias
-100.0－100.0% 0.0% 0.1% ○
F16.25
Analogue output AO2
gain
0.0－200.0% 100.0% 0.1% ○
F16.26
DO2 maximum output
pulse frequency
0.1－50.0kHz 10.0kHz 0.1kHz ○
Group F17 SCI Communication Parameters (refer to pages 106
－
107)
