Shenzhen Hpmont Technology Co., Ltd Chapter 6 Function Introduction
HD30 Series Inverters User Manual ―55―
No. Name Description Range
【
factory setting
】
d00.10 Inverter status
【
Actual value
】
Display the inverter status, as shown in the following table:
Bit3 Bit2 Bit1 Bit0
Units
Zero speed running
0: In non-zero speed
runing
1: In zero speed running
Forward/reverse
0: Forward
1: Reverse
Run/stop
0: Stop
1: Run
Inverter fault
0: No fault
1: Fault
Tens
DC braking
0: Non-DC braking
status
1: In DC braking
Reserved
Bit1&Bit0:
Acceleration/deceleration/constant
00: Constant
11: Constant
01: Acceleration
10: Deceleration
Hundreds Reserved
Speed limiting
value
0: Not in the
limiting
1: In the limiting
Reserved
Parameter
auto-tuning
0: No auto-tuning
1: Auto-tuning
Thousands Reserved Reserved
Current
limiting
0: In
1: Not in
Stall overvoltage
0: In
1: Not in
123
d00.11
Master setting frequency source
【Actual value】
Display the master setting frequency source, see parameter F00.10.
d00.12
Master setting frequency
【Actual value】
Display the master setting frequency.
d00.13
Auxiliary setting frequency
【Actual value】
Display the auxiliary setting frequency.
d00.14
Setting frequency
【Actual value】
Display the target setting frequency.
d00.15
Reference frequency (after acceleration/deceleration)
【Actual value】
Display the reference frequency for the change of the acceleration/deceleration.
d00.16
Output frequency
【Actual value】
Display the output frequency.
d00.17
Setting RPM
【Actual value】
Display the setting RPM.
d00.18
Running RPM
【Actual value】
Display the running RPM.
d00.19
Three-phase power supply input sequence phase
【Actual value】
Display the sequence phase of the three-phase input.
• 0: Positive sequence: L1(R) preceding L2(S) preceding L3(T).
• 1: Negative sequence: L1(R) preceding L3(T) preceding L2(S).
