No. Name Description Range
【
factory setting
】
d00.20 Output voltage
【
Actual value
】
Display output voltage.
d00.21 Output current
【
Actual value
】
Display output current.
d00.22 Reserved
d00.23
Output torque
【Actual value】
Display output torque which is the relative percentage of the motor rated torque.
d00.24
Output power
【Actual value】
Display the present actual output power whose unit is 0.1kW.
d00.25
DC bus voltage
【Actual value】
Display DC bus voltage.
d00.26
Potentiometer input voltage of the display panel
【Actual value】
Display potentiometer input voltage of the display panel.
d00.27
AI1 input voltage
【Actual value】
Display AI1 input voltage.
d00.28
AI1 input voltage (after disposal)
【Actual value】
Display A1 input voltage which is disposed by the gain, bias, analogue curve and filter.
d00.29
AI2 input voltage
【Actual value】
Display AI2 input voltage. When AI2 selects current input, the corresponding relations are: 0V
corresponds to 0mA and 10.00V corresponds to 20mA.
d00.30
AI2 input voltage (after disposal)
【Actual value】
Display A2 input voltage which is disposed by the gain, bias, analogue curve and filter.
d00.31
AI3 input voltage
【Actual value】
Display AI3 input voltage.
• Selecting HD30-EIO, the AI3 corresponds to the AI3 of HD30-EIO. When AI3 selects current
input, the corresponding relations are: 0V corresponds to 0mA and 10.00V corresponds to 20mA.
• Selecting HD30-PIO, the AI3 corresponds to the channel one of HD30-PIO. When the channel
one selects current input, the corresponding relations are: 0V corresponds to 0A and 24.00V
corresponds to 1A.
d00.32
AI3 input voltage (after disposal)
【Actual value】
Display A3 input voltage which is disposed by the gain, bias, analogue curve and filter.
d00.33
AI4 input voltage
【Actual value】
Display AI4 input voltage.
• Selecting HD30-EIO, the AI4 corresponds to the AI4 of HD30-EIO.When AI4 selects current input,
the corresponding relations are: 0V corresponds to 0mA and 10.00V corresponds to 20mA.
• Selecting HD30-PIO, the AI4 corresponds to the channel two of HD30-PIO. When the channel two
selects current input, the corresponding relations are: 0V corresponds to 0A and 24.00V
corresponds to 1A.
d00.34
AI4 input voltage (after disposal)
【Actual value】
Display A4 input voltage which is disposed by the gain, bias, analogue curve and filter.
d00.35
DI6 terminal pulse input frequency
【Actual value】
Display DI6 terminal pulse input frequency(Hz).
