Shenzhen Hpmont Technology Co., Ltd Chapter 6 Function Introduction
HD30 Series Inverters User Manual ―57―
No. Name Description Range
factory setting
d00.36 AO1 output
Actual value
Display AO1 output. When AO1 selects current output, the corresponding relations are: 0V
corresponds to 0mA and 10.00V corresponds to 20mA.
d00.37 AO2 output
Actual value
Display AO2 output. When AO2 selects current output, the corresponding relations are: 0V
corresponds to 0mA and 10.00V corresponds to 20mA.
d00.38 High-speed output pulse frequency
Actual value
Display high-speed output pulse frequency(Hz).
d00.39 Heatsink temperature
Actual value
Display heatsink temperature.
d00.40 Setting line speed
Actual value
Display the setting line speed.
d00.41 Reference line speed
Actual value
Display the reference line speed.
d00.42 Reserved
d00.44 Process PID reference
Actual value
Display process PID reference relative to full scale (10.00V) percentage.
d00.45 Process PID feedback
Actual value
Display process PID feedback relative to full scale (10.00V) percentage.
d00.46 Process PID tolerance
Actual value
Display process PID tolerance relative to full scale (10.00V) percentage.
d00.47 Process PID integral item
Actual value
Display process PID integral item relative to full scale (10.00V) percentage.
d00.48 Process PID output
Actual value
Display process PID output to full scale (10.00V) percentage.
d00.49 External counting value
Actual value
Display external counting value.
d00.50 Input terminal status
Actual value
Display input terminal status. Each bit(binary) of this function parameter stands for different physical
sources which are in the below table.
• 0: The multi-function input terminals are disconnected with corresponding common terminals.
• 1: The multi-function input terminals are connected with corresponding common terminals.
Hundreds Tens Units
Bit11 Bit10 Bit9 Bit8 Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
- - - DI9 DI8 DI7 DI6 DI5 DI4 DI3 DI2 DI1
Note: Only when using HD30-EIO will the DI7
DI9 be enabled.
6
