Shenzhen Hpmont Technology Co., Ltd Chapter 2 Product Information
HD30 Series Inverters User Manual ―7―
Item Specification
Protection
Stall overvoltage Bus voltage can auto-control against overvoltage fault
Auto-limited current
protection
Output current can auto-limit against overcurrent fault
Overload pre-alarm and
alarm
Overload early pre-alarm and protect
Load loss protection Load loss alarm function
I/O phase loss
protection
I/O phase loss auto-detect and alarm function
Braking fault protection Braking detecion and alarming function
Process PID commands
and feedback loss
detection
Process PID can auto-identify whether loss the reference and
feedback or the alarm function
Power output grounding
fault protection
Power output grounding fault protection is enabled
Power output short
circuit protection
Power output short circuit protection is enabled
I/O feature
Analogue supply +10V, maximum current 100mA
Digital supply +24V, maximum current 200mA
Analogue input
AI1: voltage 0－10V
AI2: -10V－+10V/0－20mA (selectable voltage/current)
(it can be extended to 4 inputs with HD30-EIO)
Analogue output AO1, AO2: 0－10V/0－20mA (selectable voltage/current)
Digital input
DI1－DI6
Remark: DI6 can be selectable for high-frequency input
(it can be extended to 9 inputs with HD30-EIO)
Digital output
DO1, DO2
Remark: DO2 can be selectable for high-frequency output
Programmable relay
output
R1A/R1B/R1C: contact rating 250VAC/3A or 30VDC/1A
(it can be extended to 4 outputs with HD30-EIO)
Communication
SCI communication RS-485 interface
2
