Shenzhen Hpmont Technology Co., Ltd Chapter 6 Function Introduction
HD30 Series Inverters User Manual ―63―
6.2.2 Group F01 Protection of Parameters
No. Name Description Range
factory setting
F01.00 User’s password 00000
65535
00000
XXXXX: To enable the password protection function, set any non-zero number as the password.
• Once the password is set, if you want to change any parameter you must input correct password.
Otherwise, all the parameters cannot be changed but only read.
• When input correct password, by pressing the key to exit to stop/run display status or by
detecting that there is no press on the display panel within 5 minutes, the user’s password will be
valid. It is necessary to input correct password if you want to change parameters. It will restart
when there is no press on the display panel within 5 minutes.
00000: The factory setting of F01.00 is 00000, namely the password protection function is disabled.
• If the user unlocks the password, it means clearing the user’s password.
• To unlock, change and clear the user’s password, see section 5.2.3.
F01.01 Menu mode selection 00
11
10
Units:
0: Full menu mode. All function parameters can be displayed in this menu.
1: Checking menu mode. Only different from factory setting parameters can be displayed.
Tens:
0: Does not lock the parameter mapping relationship of Group U and Group F.
1: Lock the parameter mapping relationship of Group U and Group F.
F01.02 Function code parameter initialization (download) 0
6
0
0: No operation. The inverter is in regular parameter read/write status.
• Whether can change the parameter it depends on the user’s
password status and the actual operating conditions.
1: Restore to factory settings.
• Except F01.00, F01.02, F01.03, Group F08, F13.01－F13.15,
F19.15, F19.19, F19.24, F20.08, F20.09, F20.21－F20.37,
F23.00 and Group y.
• Operation steps: If set F01.02 = 1, press to ensure and the parameters are restored to
factory settings. The display panel dispalys “rESEt”. Then the display panel will display
parameters in stop status after finish restoring to factory setting.
2: Download the display panel EEPROM parameter 1 to the current function code settings.
3: Download the display panel EEPROM parameter 2 to the current function code settings.
4: Clear fault information. The fault history of F20.21－F20.37 will be clear.
5: Download the display panel EEPROM parameter 1 to the current function code settings (including
the motor parameters).
6: Download the display panel EEPROM parameter 2 to the current function code settings (including
the motor parameters).
Display panel EEPROM parameter initialization (upload)
0: No operation. The inverter is in regular parameter read/write status.
1: Upload the current function code settings to the display panel
EEPROM parameter 1.
2: Upload the current function code settings to the display panel
EEPROM parameter 2.
Note: F01.00, F01.02, F01.03, F20.21
F20.37 and Group y do not
upload or download.
Display panel
HD30
Download
Display panel stored
function parameter
F01.02=2/3/5/6
Display panel
HD30
Upload
HD30 present setting
function parameter
F01.03=1/2
6
