hpmont HD30-4T055G/075P User Manual

Chapter 3 Mechanical Installation Shenzhen Hpmont Technology Co., Ltd
―14― HD30 Series Inverters User Manual
Table 3-2 HD30 dimensions
Structure
size
Model
Dimension (mm) Mounting size (mm)
GW
(kg)
Figure
W H D W1 H1 H2 d
Frame 1
HD30-2D0P4G
135 241 162 91 226 220 5 2.4 Figure 1
HD30-2D0P7G
HD30-2D1P5G
HD30-2D2P2G
HD30-4T0P7G
HD30-4T1P5G
HD30-4T2P2G
Frame 2
HD30-2T3P7G
165 266 190 115 253 245 5 4.4 Figure 1 HD30-4T3P7G/5P5P
HD30-4T5P5G/7P5P
Frame 3
HD30-2T5P5G
200 299 210 146 286 280 5 5.8 Figure 1 HD30-4T7P5G/011P
HD30-4T011G/015P
Frame 4
HD30-2T7P5G
235 353 222 167 337 330 7 8.2 Figure 1 HD30-4T015G/018P
HD30-4T018G/022P
Frame 5
HD30-2T011G
290 469 240 235 445 430 8 20.4 Figure 2
HD30-2T015G
HD30-2T018G
HD30-4T022G/030P
HD30-4T030G/037P
Frame 6
HD30-2T022G
380 598 290 260 576 550 10 48 Figure 2
HD30-2T030G
HD30-2T037G
HD30-4T037G/045P
HD30-4T045G/055P
HD30-4T055G/075P
Frame 7
HD30-2T045G
500 721 330 343 696 670 12 80 Figure 3
HD30-2T055G
HD30-2T075G
HD30-4T075G/090P
HD30-4T090G/110P
HD30-4T110G/132P
Frame 8
HD30-4T132G/160P
620 917 360 450 890 850 12 115 Figure 3 HD30-4T160G/200P
HD30-4T200G/220P
Frame 9
HD30-4T220G/250P
740 1067 370 520 1040 1000 14 150 Figure 3 HD30-4T250G/280P
HD30-4T280G/315P
