Chapter 6 Function Introduction Shenzhen Hpmont Technology Co., Ltd
―58― HD30 Series Inverters User Manual
No. Name Description Range
factory setting
d00.51 Output terminal status
Actual value
Display output terminal status. Each bit(binary) of this function parameter stands for different physical
sources which are in the below table.
• 0: The multi-function output terminals are disconnected with corresponding common terminals.
• 1: The multi-function output terminals are connected with corresponding common terminals.
Tens Units
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
- - RLY4 RLY3 RLY2 RLY1 DO2 DO1
Note: Only when using HD30-EIO will the RLY2
RLY4 be enabled.
d00.52 MODBUS communication status
Actual value
Display MODBUS communication status.
0: Normal.
1: Communication timeout.
2: Incorrect data frame head.
3: Incorrect data frame checking.
4: Incorrect data frame content.
d00.53 Actual length
Actual value
d00.53 displays actual length; d00.54 displays total length.
d00.56 Total time at operation
Actual value
d00.55 display total time at power-on; d00.56 displays total time at operation. The unit is hour.
d00.57 High bit of motor total energy consumption
Actual value
Low bit of motor total energy consumption
Display the high bit (d00.57) and the low bit (d00.58) of the motor total energy consumption.
High bit of energy consumption at this time running
d00.60 Low bit of energy consumption at this time running
Actual value
Display the high bit (d00.59) and the low bit (d00.60) of energy consumption at this time running.
d00.61 Present fault
Actual value
Display the present fault.
• Displaying 100 means the undervoltage.
