hpmont HD30-4T055G/075P User Manual

Shenzhen Hpmont Technology Co., Ltd Chapter 6 Function Introduction
HD30 Series Inverters User Manual ―79―
No. Name Description Range
【
factory setting
】
F07.01 Wobble operation mode 0000
－
1111
【
0000
】
Units: Start mode of wobble operation.
• 0: Auto start. The inverter will first operate at the preset frequency of wobble operation (F07.02) for
certain time (F07.03), and then enter wobble mode automatically.
• 1: Manual start. If the multi-function terminal is set as No.36 function (set as wobble start function)
and the signal is enabled, the inverter will enter wobble mode. If the terminal is disabled, the
inverter will end wobble operation and operate at the preset frequency of wobble operation
(F07.02).
Tens: Wobble operation amplitude. Refer to parameter F07.04.
• 0: Relative to the wobble central frequency.
• 1: Relative to the maximum output frequency.
Hundreds: Restart mode of wobble operation.
• 0: The inverter restarts the wobble operation as per the recorded frequency and direction when it
stops last time.
• 1: The inverter restarts the wobble operation from 0 Hz.
Thousands: Save the wobble operation parameters at power outage
• 0: Saved. When the hundreds of F07.01 is set as 0, the wobble operation parameters will be
saved when power outage occurs.
• 1: Not be saved.
F07.02 Preset wobble frequency 0.00
－
upper limit
【
0.00Hz
】
F07.03
Holding time of preset wobble frequency
0.0－999.9【0.0s】
F07.02 defines the inverter’s running frequency before entering wobble mode.
F07.03 defines the time that the inverter operates at the preset wobble frequency.
• Only when select auto start (set units of F07.01 as 0) will F07.03 be enabled.
F07.04
Wobble amplitude
0.0－50.0【0.0%】
Relative to central frequency: F
W
= central frequency × F07.04.
• Wobble central frequency is the frequency value set by F00.10 (frequency reference source).
Relative to maximum output frequency: F
W
= maximum output frequency F00.06 × F07.04.
F07.05
Jump frequency
0.0－F07.04【0.0%】
The setting is the percentage of wobble amplitude. There is not jump frquency if set as 0.
F07.06
Wobble operation cycle
0.1－999.9【10.0s】
F07.06 defines a complete cycle of wobble operation including rising and falling processes.
F07.07
Rising time of triangle wave
0.0－100.0【50.0%】
Relative to wobble operation cycle of the F07.06, F07.07 defines the rising and the falling time of
wobble operation and their unit is s.
• Rising time of wobble operation ＝ F07.06 × F07.07.
• Falling time of wobble operation ＝ F07.06 × (1 - F07.07).
