6.3 Group U User Menu Mode Display Parameters
When the user select fewer function parameters which is scattered in the function menu, the user
can map the function menu to the user menu. Then the user can only operate in the user menu to
read and write the required function parameters. It not only can avoid the frequently switch
among the parameter groups but also can arrange the menu order according to our own habits.
That will be much easier to memory and operate. Refer to Appendix B about the record.
The concrete use is illustrated as the following example:
If you want to map F00.13 (starting frequency digital setting) to the user menu map 1 (U00.00),
you only need to set U00.00 as 00.13 (corresponding to F00.13) and then you can directly control
F00.13 via read-write U00.01 (setting value of map 1), which is the same effect as the direct
operation of F00.13.
No. Name Description Range
【
factory setting
】
U00.00 User menu map of setting 1 00.00
－
23.02
，
99.99
【
00.01
】
U00.02
User menu map of setting 2
00.00－23.02，99.99【00.06】
U00.04 User menu map of setting 3 00.00
－
23.02
，
99.99
【
00.08
】
U00.06
User menu map of setting 4
00.00－23.02，99.99【00.13】
U00.08 User menu map of setting 5 00.00
－
23.02
，
99.99
【
00.10
】
U00.10
User menu map of setting 6
00.00－23.02，99.99【00.11】
U00.12 User menu map of setting 7 00.00
－
23.02
，
99.99
【
02.13
】
U00.14
User menu map of setting 8
00.00－23.02，99.99【03.01】
U00.16 User menu map of setting 9 00.00
－
23.02
，
99.99
【
03.02
】
U00.18
User menu map of setting 10
00.00－23.02，99.99【08.00】
U00.20 User menu map of setting 11 00.00
－
23.02
，
99.99
【
08.01
】
U00.22
User menu map of setting 12
00.00－23.02，99.99【08.02】
U00.24 User menu map of setting 13 00.00
－
23.02
，
99.99
【
08.03
】
U00.26
User menu map of setting 14
00.00－23.02，99.99【08.04】
U00.28 User menu map of setting 15
－
U00.30
User menu map of setting 16
－
If set as 99.99, there is no parameter map function.
U00.01 The setting value of map 1
The same as the selected
parameter
【
0
】
U00.03 The setting value of map 2
U00.05
The setting value of map 3
U00.07 The setting value of map 4
U00.09
The setting value of map 5
U00.11 The setting value of map 6
U00.13 The setting value of map 7
U00.15 The setting value of map 8
U00.17
The setting value of map 9
U00.19 The setting value of map 10
U00.21
The setting value of map 11
U00.23 The setting value of map 12
U00.25 The setting value of map 13
U00.27 The setting value of map 14
U00.29
The setting value of map 15
6
