QUICK START for USER MENU of GROUP U
User menu of Group U
After map the parameters which will be used to the Group U, simply operating the Group U can
directly achieve parameters of read and write.
When the user selects fewer functional parameters which are scattered in the function menu, the
user can map the function menu to the user menu. Then the user can only operate in the user
menu to read and write the required function parameters. It not only can avoid the frequently
switch among the parameter groups but also can arrange the menu order according to our own
habits. That will be much easier to memory and operate.
Note:
It need set the tens of value of parameter F01.01 as 0 (does not lock the parameter mapping
relationship of Group U and Group F) so that you can modify Group U. The factory setting is 1
(lock the parameter mapping relationship of Group U and Group F).
Example for use
If you want to map F00.13 to the user menu map 1 (U00.00) and F03.01 to the user menu map 2
(U00.02), you only need to set U00.00 and U00.02 but do not set the mapping setting value
(U00.01 and U00.03), as following table.
Which, two digits of setting value before the decimal point represent the functional group number
of Group F, and the other two digits after the decimal point represent the intergroup number.
No. Name Value Range
U00.00
User menu map of
setting 1
00.13
00.00－23.03,99.99【Factory setting】
If set as 99.99, there is no parameter
map function
U00.01
The setting value of map
1
Without setting
U00.02
User menu map of
setting 2
03.01
00.00－23.03,99.99【Factory setting】
If set as 99.99, there is no parameter
map function
U00.03
The setting value of map
2
Without setting
After finish setting, modifying the setting value of map (U00.01 and U00.03) can change value of
F00.13 and F03.01 automatically.
