Shenzhen Hpmont Technology Co., Ltd Chapter 6 Function Introduction
HD30 Series Inverters User Manual ―69―
No. Name Description Range
factory setting
F03.09 Switching frequency of acceleration time 2 and time 1 0.00
upper limit
0.00Hz
When the running frequency is smaller than the F03.09 setting, it will accelerate according to
acceleration time 2; Otherwise it will accelerate according to acceleration time 1.
• When use terminals to select acceleration/deceleration time (set multi-function terminal as
number 26 and 27 function), F03.09 is disabled.
F03.10 Switching frequency of deceleration time 2 and time 1 0.00
upper limit
0.00Hz
When the running frequency is smaller than the F03.10 setting, it will decelerate according to
deceleration time 2; Otherwise it will decelerate according to deceleration time 1.
• When use terminals to select acceleration/deceleration time (set multi-function terminal as
number 26 and 27 function), F03.10 is disabled.
F03.11 S-curve characteristic time at starting acceleration 0.00
2.50
0.20s
S-curve characteristic time at ending acceleration
F03.13 S-curve characteristic time at starting deceleration 0.00
2.50
0.20s
S-curve characteristic time at ending deceleration
Refer to the figure of parameter F03.00.
Acceleration time of jog operation
F03.16 Deceleration time of jog operation 0.1
6000.0
6.0s
F03.15 and F03.16 define the acceleration/deceleration time of jog operation.
F03.17 Deceleration time of emergency stop 0.1
6000.0
10.0s
It defines the deceleration time of emergency stop.
6
