3.3 Peripherals Connection
3.3.1 Interface Cable Connection
The standard for the printer’s interface cable shows in the following.
- USB B-Type Cable
- RS-232C Cable
- RJ45 Cable
Please follow the instructions to connect the cable.
1. Make sure the printer is turned off.
2. Please plug in the cables.
-Insert the USB B-Type cable into the USB port.
-Insert the RS-232C cable into the serial port.
-Insert the RJ45 cable into the ethernet port.
3.3.2 Bluetooth Connection
PDA with Bluetooth interface, laptop and other information terminals can drive the mobile
thermal printer. Instructions as follows:
1. Power on printer.
2. Primary device search for outer Bluetooth devices.
3. If there are some outer Bluetooth devices, choose HD100.
4. Finish pairing.
Detailed pairing methods, please refer to primary devices Bluetooth Names. After pairing,
primary devices with virtual Bluetooth interface (smart phone, pocket PC, palm, notebook) can
drive mobile thermal printer to print through such virtual Bluetooth interface.
Note: The original code is 1234.
