HRESYS TL-LFP Series User Manual

TL-LFP Series LiFePO
4
Battery Operation Manual
under-temper
ature,
over-current
protection
Discharge
Normal
Normally
on
OFF
According to the SOC
——
Temp Alarm
Normally
on
Flash
2
——
Under voltage
protection
Flash 1
OFF
Over
temperature,
under-temper
ature,
over-current
protection
Flash 1
Flash
2
Charge / Discharge /
Standby
The fault
OFF
Norm
ally
ON
OFF
LED Flash State
Light
Extinguish
Flash1
0.25S
3.75S
Flash2
0.5S
0.5S
Flash3
0.5S
1.5S
Annex 2
–
Instructions for ADD Dialing
ADD is applicable to modules connected in parallel. ADD consists of four binary bits, and
maximum quantity of batteries connected in parallel is 64pcs (2^6). BMS only identify ADD
dialing one time after reset, so reset BMS as change ADD dialing.
Annexed Table 2.1 –Instruction for Addresses of Communication
Instructions for ADD Dialing
Module No.
Binary Code
Remarks
1
2
3
4
5
6
OFF
OFF
OFF
OFF
OFF
OFF
PACK 1
000000
Master PACK, supports
RS232
ON
OFF
OFF
OFF
OFF
OFF
PACK 2
000001
Slave PACK
OFF
ON
OFF
OFF
OFF
OFF
PACK 3
000010
Slave PACK
ON
ON
OFF
OFF
OFF
OFF
PACK 4
000011
Slave PACK
