HRESYS TL-LFP Series User Manual

TL-LFP Series liFePO
4
Battery Operation Manual
6
12
LCD（Optional）
LCD display
Displays current system total voltage, current and battery status
13
GND
Protective
ground
M4 screw
4.5 - Shipment
The battery should be packed in cartons under the condition of half capacity 20%-50% for
shipment. The violent vibration, impaction or squeezing should be avoided in the transport
process; neither is exposed in the sunlight nor rain. The batteries shall be shipped by normal
transportation such as by road, by train, by ocean or by air.
4.6 – Installation
Unboxing & Inspection
 Please read this manual before installation.
 Please inspect the package before unboxing, if any destroy with appearance, contact
with the supplier as soon as possible.
 This device shall be installed and operated by professionals.
Preparation for Installation
 Batteries shall not be placed in direct sunshine or close to heat source.
 Batteries shall be installed in place with good ventilation to assure enough heat
dissipation.
 Batteries shall be placed in are with clean ambient and low humidity.
 Heavy weight shall not be placed on any cable.
 Required tools and materials are available. Use insulated tools. The following figure is
for reference only.
Item
Tool Item
Remark for use
1
Insulation gloves
Insulation protection for body
2
Insulation taps
Insulation protection for tools
3
Screw drivers
Fix the cables of the batteries & power plant
4
Multi meter
Measure the module voltage in commission
5
Current meter
Measure the module current in commission
6
USB to rs485 cable
For communication between the batteries and laptop
7
Laptop
Operate the software
