OPERATING YOUR BOILER (continued) PAGE 35
_____________________________________________________________________________________________________________________________________________________________________________________
AQUASTAT CONTROL SETTINGS DURING WINTER (HEATING SEASON)
Before you start your boiler make certain the aquastats are set as follows:
Honeywell L8124C (on boiler)
Scale Setting Function
LO
210 ° F
Boiler Overheat... starts Circulator C-3 and overrides room
thermostat for “dump zone” to dissipate excess heat
HI
180 ° F
Boiler Operating temperature for all Modes
DIFF
10 ° F
Operating Differential
Honeywell L6081A (on boiler)
Scale Setting Function
LO
165 ° F
Temperature setting at which Circulator C-3 starts operating
HI
200 ° F
Backup high temperature limit for all modes
DIFF
10 ° F
Operating Differential
Honeywell L8151A (on optional heat storage tank)
Scale Setting Function
LO
150 ° F
Temperature setting at which oil or gas burner starts again after
heat storage tank has been heated up to “HI” setting on L8151A
and then cooled down.
HI
160 ° F
Heat Storage Tank Operating Temperature when being heated by
oil or gas burner when the boiler is in either the “BACK-UP ONLY”
or the “AUTO BACK-UP” operating mode.
DIFF
10 ° F
Operating Differential
NOTE: When a heat storage tank system is not
being used the Honeywell L8151A aquastat
will not be used. A jumper wire must be installed between Terminal 1 and Terminal 3
on the boiler control panel’s External 24 Volt Terminal Strip (refer to “Field Wiring
Diagrams” on page 24 and 24.1).
