01
Box Contents
6S-3900g 8S-4100
Installed
HOBBYWING 120A HV Pro Brushless ESC(6-8S)-
Installed
Servos:（twin bearings,metal shell and digital servos)
12g*9pcs 40G*1pcs
Installed
Battery:
8S 5000mAh 40C Li-Po
6S 5000mAh 40C
Required to Complete
Recommended Transmitter:
Full-Range 6-8S channel (or more) 2.4GHz with Spektrum
FUTABA technology with adjustable Dual Rates.
(956mm)
(1688mm)
Brushless Outrunner Motor, 4253/1200KV(6S)
4253/1100KV(8s)
Required to Complete
ATTENTION:
EDF jets require Li-PO batteries with a high discharge rating (Crating) for increased
safety and optimal performance. We recommend using Li-Po batteries with a minimum
of 40C or above. For 8S systems that require two batteries in series, the C rating must
remain the same on both batteries for better consistency and performance. Below is the
power output references:
6S-5000mAh 40C 120A or above = 8.8lb / 4kg thrust
8S-5000MA 40C 105A or above = 11lb / 5kg thrust
Specifications
External UBEC - 8A
