03
1.
Install the canards by placing them over the control rod and securing it in place
with the provided screws (PM3x5mm). Repeat this step for the other side.
PM ×5mm3
2.1.Insert the wing spar into one of the main wings. Push the wingspar into the wing
until its center point has reached the edge of the wing as shown in the illustration.
Now install the wing with the spar onto the fuselage wing mounting panels and secure
it with the provided wing mounting screws. After finishing this procedure, install the
second main wing as required.
BALANCE OF CANARD
MUST BE CONSISTENT
PA3.0×10mm
ASSEMBLY
Cockpit can be removed by pressing
the sides and lifting up towards the front end.
Install the main wing while
ensuring that it is secure so that it
can withstand the plug of the
fuselage. Otherwise, poor contact
will exist.
