4.Glue the tail exhaust nozzle piece as shown below. First, apply the foam-safe adhesive
within the inner slotted area of the rear exhaust exit as shown in the first figure. Then,
install the clear compressing plastic air-duct where the glue was applied on the slotted
area as shown in the second figure. Apply foam-safe adhesive on the exhaust nozzle as
shown in the third figure and install.
3.Install the ventral fin mounts with the glue as shown (omit if pre-installed). Repeat
this step for the other side. After the ventral fin mounts are glued, install the ventral
fins with the provided screws.
5.Install the vertical stabilizer into the mounting area at the end of the fuselage with
the provided screws as shown in below.
PA3×8mm
04
