HSM 411.2 Paper shredder
7. Maintenance and care
Cleaning:
• Switch off the shredder, pull out the mains
plug.
• When cleaning only use a soft cloth and a
mild soap-water solution. Never use scou-
When the cutting capacity drops or
the noise increases:
• Lift the inspection door on the
top of the device and spray spe-
cial cutting block oil on the blade
rollers of the cutting device.
ring agents, cleaning fluid, petroleum or
• Run cutting system forwards and
thinners.
backwards several times without
feeding paper. Paper dust and
particles are shaken off.
8. Technical Data
Cutting type Strip cut Cross cut
Shred size (mm) 5.8 3.9 3.9 x 50 1.9 x 15 0.78x11 1 x 5
Sa fe ty ra ting DIN 32757 – 1 2 2 3 4 5 Level 6*
Cutting ca pa ci ty (sheets), DIN A4 70 g/m
2
80 g/m
2
65 - 67
51 - 53
48 - 50
38 - 40
38 - 40
33 - 35
26 - 28
20 - 22
17 - 19
12 - 14
9 - 10
7 - 8
Weight 74 kg 82 kg
Noise level (Idle running/ load) 60 dB(A) / 68 dB(A) 60 dB(A) / 75 dB(A)
Cutting speed 100 mm/s 110 mm
Lo ading width 400 mm
Voltage 230 V, 50 Hz
100 V, 50/60 Hz – 115 V, 60 Hz
Power
for the maximum number of sheets 2100 W
Dimensions W x D x H (mm) 595 x 470 x 990
Volume of shredded material bag 146 l
* HSM-specification
Technical and optical modifi cations reserved
