8-116 Periodic Maintenance and Adjustment
1. Brake pad 2. Brake pad plate
a. Brake pad thickness
Checking the brake fluid level
Insufficient brake fluid may let air enter the
brake system, possibly causing the brakes
to become ineffective.
Before riding, check that the brake fluid is
above the minimum level and replenish
when necessary. A low brake fluid level
may indicate worn brake pads and/or
brake system leakage. If the brake fluid
level is low, be sure to check the brake
pads for wear and the brake system for
leakage. The rear brake fluid master
cylinder reservoir is located
1. Minimum level mark
