8-115 Periodic Maintenance and Adjustment
1. Brake pad a. Brake pad thickness
NOTE: The wheels
need to be removed to check the brake
pads. (See pages 8-37—8-38 for removal
and installation procedures.)
Checking the rear brake pads
Check the brake pads for damage and
wear. If the thickness is less than 1.0 mm
(0.04 in), have a dealer replace the pads.
To Next Page
