5-25 Pre Operation Checks
If there are more than one fault code, they will be shown in rolling sequence. When
fault codes are present, in order to see the time press the clock button, the time will be
shown. Then after five seconds, the fault code returns again. Only after the fault is
fixed, will the time show automatically.
The description for the fault codes are shown in Chapter 11 of this manual.
Fuel level indicator
The fuel level display will indicate the fuel volume. When the fuel is getting low the fuel
pump symbol will flash
[1]. Fuel level indicator [2]. Fuel level warning indicator
Handlebar switches
1. Light switch “ / / OFF/”
2. Start switch “ ”
3. Left/right turning light switch
4..Engine stop switch “ / ”
5. Horn switch
6. Emergency light switch
Light switch “ / /OFF/ ”
Set the switch to “ ” to turn on the low beam and the taillight.
