8-126 Periodic Maintenance and Adjustment
Wheel removal
1. Loosen the wheel nuts.
2. Elevate the TRACTOR and place a
suitable stand under the frame.
3. Remove the nuts from the wheel.
4. Remove the wheel.
1. Nut (×4)
Wheel installation
1. Install the wheel and the nuts.
NOTE: The arrow
mark on the tire must point toward the
rotating direction of the wheel.
Tapered nuts are used for both the front
and rear wheels. Install the nut with its
tapered side towards the wheel.
