POTENTIAL HAZARD
Improper adjustment of the speed limit-ere
and throttle.
WHAT CAN HAPPEN
The throttle cable could be damaged.
Improper throttle operation could result.
You could lose control, have an accident or
be injured.
HOW TO AVOID THE HAZARD
Do not turn the adjusting screw out more
than 12 mm (0.47 in). Always make sure the
throttle lever free play is adjusted to 3-5 mm
(0.12-0.20 in).
Front brake lever
The front brake lever is located on the right handlebar. Pull it toward the handlebar to
apply the front brake.
1. Brake lever
Brake pedal and rear brake lever
The brake pedal is located on the right side of the TRACTOR and the rear brake lever
is located on the left handlebar. Push down on the pedal or pull the lever toward the
handlebar to apply the rear brake.
1. Brake pedal
