HTC 280 - Page 13

To grind at an edge
1. Remove the screws (A) and the hatch (B).
A
B
2. Attach the hatch onto the holder.
3. A guard behind the hatch prevents damage to the
wall. Remove the 2 screws and the guard if it is
necessary to grind near the wall.
4. Lift the foot pedal.
5. Use your foot to give the wheels the right angle.
6. If it is necessary to grind on the right side, the
wheels must point in the left direction.
917 - 001 -
13
