9 Technical data
9.1 Technical data , HTC 800RXP
HTC 800RXP
Output 18,3 kW / 24,5 hp
Control voltage 12 V / 24 V
Total machine weight 525 kg / 1160 lbs
Chassis weight (including weights) 235 kg / 518 lbs
Weight, grinding head 290 kg / 641 lbs
Weights 2x33 kg / 2x73 lbs
Grinding diameter 800 mm / 31,5 inch
Grinding pressure, position 1 350 kg / 770 lbs
Grinding pressure, position 2 269 kg / 595 lbs
Grinding pressure, position 3 248 kg / 548 lbs
Rotational speed, grinding discs 815 rpm
Grinding discs 270 mm / 6,9 inch
Storage temperature (short term, e.g. transport) -30 - +50 C
o
/ -22 - +122 F
o
Working temperature -5 - +40 C
o
/ 23 - 104 F
o
Humidity 5 - 90 %
Sound pressure level* N/A dBA
Sound power level* N/A dBA
Vibrations, Floor preparation (T-Rex) 3,7 m/s
2
Permitted daily exposure, Floor preparation (T-Rex) 14,6 h
Transmitter frequency 433 MHz (433.100 - 434.750
MHz)
Transmitter power < 10 mW
* This machine is tested for noise in accordance with ISO 3741 and ISO 11202.
** Hand and arm-weighted vibration level [m/s²] for HTC 800RXP have been measured using equipment approved in
accordance with ISO 5349-1:2001. Measurement uncertainty for the measuring equipment is given as +/- 2%. The
machine has been tested in accordance with ISO 5349-2:2001 and ISO 20643:2005 in order to identify the operations
that contribute to the most frequent vibration exposures. At vibration levels > 2.5 m/s², the exposure time should be
limited in accordance with the table above. For vibration levels > 5 m/s², immediate measures must be taken by the
employer to ensure that the exposure time does not exceed the time specified in the table below.
888 - 001 - Technical data - 25
