HTP Pro Pulse 220 MTS User Manual

6
Pro Pulse 220 MTS Specifications
Maximum Output Amperage 200 (220 for 10 seconds)
Minimum Output Amperage
MIG: 12
TIG & Stick: 4
Maximum Recommended Thickness
*Single pass capacity varies depending on the material
being welded and the setting of the machine.
1/4” to 3/8”
Duty-Cycle
35% @ 200A @ 77º F
100% @ 140A @ 77º F
25% @ 200A @ 104º F
60% @ 140A @ 104º F
100% @ 120A @ 104º F
Open Circuit Voltage
75
Electronic Overload Protection
Yes
Cooling (On-demand, electric fan, variable speed) Air
Wire Spool Capacity
*Up to a 44 Lb. weight capacity; 8” spools recommended
for Double Pulse aluminum welding.
8” & 12”
Wire Diameter
*Depends on the material being welded (not all wire can
be welded in all sizes.
.023” to .045”
Input Voltage
208 to 240v
Input Amperage
MIG: 35
TIG & Stick: 40
Frequency
50/60 Hz
Wire Feed Rate (In./Min.) 55 to 630
Size (Length x Width x Height) 19-3/4” x 10” x 14-1/2”
Weight
*Without wire and cables.
42 Lbs.
