The combustion air intake grille should be located in a well ventilated place. To prevent corrosion, the
c
ombustion air must be free of aggressive substances. Aggressive substances are halogenated
hydrocarbons that contain chlorine or fluorine. These substances are found in solvents, paints,
adhesives, gases or liquid propellants and household cleaners. If these conditions cannot be
guaranteed, another location should be chosen for the air intake.
3. UNIT INSTALLATION
8
3.3 Modes of installation
2.5 Internal cable diagram
Connecting the water flow sensor
Ignition Pin Connection
Valve switch connection
Gas proportional valve connection
Valve switch connection
Induction pin connection
Ground wire
screen
Power connection
AC motor connection
Transformer
To Next Page
