Sensore di temperatura R-T tabella di conversione
R25 = 5.0KΩ ± 1,0% B25-50 = 3470K ± 1,0%
℃
Rmin /
KOhmios
KOhmios Rmax /
KOhmios
℃
Rmin
/
KOhmios
KOhmios
Rmax /
KOhmios
℃
Rmin /
KOhmios
KOhmios Rmax /
KOhmi
os
-20
36.195
37.303
38.441
21
5,779
5.847
5,914
62
1.343
1,374
1,406
-19
34.402
35.437
36.499
22
5.558
5.62
5,683
63
1.301
1,331
1,362
-18
32.709
33.676
34.668
23
5.346
5.404
5,463
64
1.26
1.29
1.321
-17
31.109
32.012
32.939
24
5.144
5.198
5.252
65
1,221
1.25
1.28
-16
29.597
30.441
31.306
25
4.95
5
5.05
66
1,183
1,212
1,242
-15
28.168
28.957
29.765
26
4,761
4,811
4,861
67
1.147
1.175
1,204
-14
26.816
27.554
28.308
27
4.58
4.63
4.68
68
1.111
1.139
1,168
-13
25.538
26.227
26.932
28
4.408
4.457
4.507
69
1,077
1.105
1.133
-12
24.328
24.972
25.631
29
4.242
4.292
4.341
70
1,045
1,072
1,099
-11
23.183
23.785
24.4
30
4,084
4.133
4.182
71
1.013
1.04
1,067
-10
22.098
22.661
23.236
31
3,933
3,981
4.03
72
0,983
1.009
1,035
-9
21.071
21.598
22.135
32
3,788
3,836
3,885
73
0,953
0,979
1.005
-8
20.098
20.59
21.093
33
3,649
3,697
3,745
74
0,925
0.95
0,975
-7
19.176
19.636
20.106
34
3,516
3,563
3,611
75
0,897
0,922
0,947
-6
18.301
18.732
19.171
35
3,388
3,435
3,483
76
0,871
0,895
0,919
-5
17.472
17.875
18.285
36
3.266
3.313
3.36
77
0,845
0,869
0,893
-4
16.686
17.063
17.446
37
3,149
3.195
3.241
78
0.82
0,843
0,867
-3
15.94
16.292
16.65
38
3.037
3.082
3.128
79
0,796
0,819
0,842
-2
15.231
15.561
15.896
39
2.929
2,974
3,019
80
0,773
0,795
0,818
-1 14.559 14.867 15.18 40 2,826 2.87 2,915 81 0,751 0,773 0,795
0
13.92
14.208
14.501
41
2,726
2.77
2.815
82
0,729
0,751
0,773
1
13.313
13.582
13.856
42
2,631
2.675
2,718
83
0,708
0,729
0,751
2
12.736
12.988
13.244
43
2.54
2,583
2,626
84
0,688
0,709
0,73
3
12.188
12.423
12.662
44
2,452
2,494
2.537
85
0,668
0,689
0,709
4
11.666
11.887
12.11
45
2,368
2,409
2,451
86
0,649
0,669
0.69
5
11.17
11.376
11.585
46
2,287
2,328
2,369
87
0,631
0,651
0,671
6
10.698
10.891
11.086
47
2.209
2.25
2.29
88
0,613
0,632
0,652
7
10.249
10.429
10.611
48
2.135
2.174
2,214
89
0,596
0,615
0,634
8
9,822
9.99
10.16
49
2,063
2.102
2.141
90
0,579
0,598
0,617
9
9,414
9,572
9.73
50
1.994
2,032
2.071
91
0,563
0,581
0.6
10
9,027
9.173
9.321
51
1,927
1.965
2.003
92
0,548
0,566
0,584
11
8,657
8,794
8,932
52
1.863
1,901
1.938
93
0,533
0.55
0,568
12
8,305
8.432
8.561
53
1.802
1,839
1,876
94
0,518
0,535
0,553
13
7.969
8,088
8.208
54
1,743
1.779
1,815
95
0,504
0,521
0,538
14
7.648
7,76
7,872
55
1,686
1,721
1,757
96
0.49
0,507
0,524
15
7.343
7.446
7.551
56
1,631
1,666
1,701
97
0,477
0,493
0.51
16
7,051
7.148
7.245
57
1,579
1,613
1,647
98
0,464
0.48
0,496
17
6,773
6,863
6,953
58
1,528
1,561
1,595
99
0,452
0,467
0,483
18
6,507
6.5911
6,675
59
1,479
1.512
1.545
100
0,439
0,455
0.47
19
6.253
6.331
6.41
60
1,432
1,464
1,497
20
6,011
6,083
6.156
61
1,386
1,418
1.451
