82
TECHNICAL SPECIFICATION
TECHNICAL DATA
150L 150LS 200L 200LS 300L 300LS 500L 500LS
Power supply
V/Ph/H
z
220-240 / 1/50
Water tank Volume L
150 200 300 500
Max power input W
700 + 1600
(e-heater)
1,420 + 1,600
(e-heater)
Max current
A
3.2+ 6.8 (e-heater)
6.2+6.8 (e-heater)
Max.outlet water
temperature
range(without
using E-heater)
°C
60
Max. water
temperature
°C
70
Min. water
temperature
°C
1
Ambient working
temp.
°C
-5-43
Max. discharge
pressure
bar
20
Min. suction pressure
bar
6
Refrigerant type
R134a
Compressor
Type
Rotary
Brand
GMCC
Model
PJ125G1C-4DZDE
PJ250M2C-4FT
Fan motor
Type
asynchronous motor
W
80
194
RPM
1280
1430
Air flow
m3/h
450
900
Duct diameter mm
177 (Fit flexible 180/200mm duct)
Max allowed pressure
of
tank
bar
10
Inside body material
of tank
SUS 304
Auxiliary electrical
heater
kW
1,6 (incoloy825)
Electronic expansion
valve
yes
Magnesium stick
yes
Solar heat exchanger
N / A
SUS316
~ 1m2
N / A
SUS316
~ 1m2
N / A
SUS316
~ 1m2
N / A
SUS316
~ 1m2
Hot water outlet
inch
G 1
Solar heat source
inlet/outlet
inch
G 3/4
