Installation procedure:
Remove the sticker from the front panel.1)
3)
Put the unit into the installation hole.2)
● When installing the unit, it should be sl-
anted down to the back to avoid the
enlargement of noise or vibration.
(Slant between 6-10mm.) (Shown at
right figure)
● The installation place should be strong
enough to avoid the enlargement of
noise or vibration.
Fill up sews in the cabinet with sponge
or foam.
Installation assistance:
●
Wall
Sunshade
board
Rubber
plate
6~10mm
Support
Horizontal line
● Use iron support. The installation
hole should be strong enough to
support the air conditioner. If it
cannot, iron support has to be used
outdoors. Iron support should be
fixed on the building (Shown at right
figure.)
Use sunshade board. Air conditioner
should avoid anything to be dropped
into it and avoid direct sunshine. If
there is no cover on it, you should
contact the seller for installing the
sunshade board. When in stalling the
sunshade board, don’t let it block the
air inlet at the side grille.
To Next Page
