Introduction to the ATN ATOM GPS
FE/GE4 and FE/GE5 are Combo interfaces and either of
them includes one SFP interface and one electrical
interface. The SFP and electrical interfaces cannot be
used at the same time.
a
NE05E-SJ
AE 905S
b
Power supply
interface
NM interface
(Console interface)
Optical interface Electrical interface
NOTE
NOTE
Before inserting an AE 905S to an optical interface, lock the ejector lever. Before
removing an AE 905S from an optical interface, loosen the ejector lever.
An AE 905S module can be installed in any GE optical interface. Installing an AE
905S module on an FE/GE2 interface is recommended to reduce reliability risks
caused by cable bending.
Lock the ejector lever.
Loosen the ejector lever.
