HUAWEI B683 Wireless Gateway V100R001
Product Description
Issue 01 (2010-11-19) Commercial in Confidence Page 8 of 22
3 Technical Specifications
3.1 Hardware Specifications
Table 3-1 Technical specifications of the B683
Item Description
Technical
standard
z
WAN: HSPA+/HSUPA/HSDPA/WCDMA/GSM/GPRS/EDGE
z
LAN: IEEE 802.3/802.3u
z
WLAN: IEEE 802.11b/g/n
HSPA/WCDMA: 2100/900MHz
WLAN: 2.4GHz～2.4835GHz
Working
frequency
band
GSM/GPRS/EDGE: 1900M/1800M/900M/850M
External
interface/
Indicators
z
One power switch: ON/OFF
z
One WLAN/WPS button
z
One Reset button
z
One dialing button
z
External antenna interface (SMA)
z
Four auto-sensing Ethernet interfaces (RJ45 and MDI/MDIX
auto-sensing): 10/100Base-T
z
One POWER (Power Adapter) interface
z
One USB 2.0 host interface
z
One Internet status indicator
z
One WLAN/WPS indicator
z
One USB indicator
z
One Power indicator
z
Four LINK/ACTIVE indicators (indicating the connection status of
the corresponding Ethernet interface)
Maximum WCDMA 24dBm (+1/-3)
