Huawei DN8245V-70 - LAN and VoIP Indicator Status; WLAN Indicator Details

Indicator Status Description
O ● The WAN port is not connected to a
network cable.
● The DSL line is not activated.
● The DSL home gateway is in bridge mode.
● The DSL home gateway does not obtain the
IP address in router mode.
WLAN Steady green The WLAN function is enabled, but no data is
being transmitted.
Blinking green ● The WLAN function is enabled, and data is
being transmitted. (Blinks twice per
second.)
● The DSL home gateway is attempting to
connect to a wireless client over the WLAN
using the WPS function. The WLAN
indicator blinks for 120s. (Blinks once per
second.)
O The WLAN function is disabled.
LAN1–LAN4 Steady green The LAN port is connected to an Ethernet
device (such as a computer) with a network
cable, but no data is being transmitted.
Blinking green The LAN port is connected to an Ethernet
device with a network cable, and data is being
transmitted.
O The LAN port is not connected to any Ethernet
device.
VoIP Steady green The DSL home gateway is registered with an
SIP server, but no data is being transmitted.
Blinking green ● The DSL home gateway is being registered
with an SIP server. (Blinks twice per
second.)
● The DSL home gateway is registered with
an SIP server, and data is being transmitted.
(Blinks 4 times per second.)
O No VoIP service, or no VoIP WAN conguration
exists.
DN8245V-70
Quick Start 01 (WIND,Greece) 3 Indicator Description
Issue 01 (2022-01-06) Copyright © Huawei Technologies Co., Ltd. 6
