2 Connecting Cables
DSL upstream connection mode
1 Telephone jack on the
wall
2 Telephone 3 Splitter
4 Desktop computer 5 STB 6 USB device
7 Power adapter 8 Laptop computer
a Line port b Telephone port c Modem port
DN8245V-70
Quick Start 01 (WIND,Greece) 2 Connecting Cables
Issue 01 (2022-01-06) Copyright © Huawei Technologies Co., Ltd. 3
