4
Follow the steps listed below to install it.
Stage Description See in
1 Connect the ADSL line. Step1
2 Connect the Ethernet cable. Step2
3 Attach the power connector. Step3
4 Turn on the HG520 and power up your system Step4
Step1
Connect the ADSL line
Method one: Plug one end of the twisted-pair ADSL cable into the
ADSL port on the rear panel of HG520 and insert the other end into the
wall socket.
Method two: You can use a separate splitter. External splitter can
divide the data and voice, then you can access the Internet and make
calls at the same time.The external splitter has three ports:
• LINE: connect to the wall jack
• PHONE: connect to the phone sets
• MODEM: connect the ADSL port of HG520
Plug one end of the twisted-pair ADSL cable into the ADSL port on the
rear panel of HG520. Connect the other end to the MODEM port of the
external splitter.
