2 Connecting the Cables and Getting
Started
2.1
Simple Connection
If your telephone line is used for the broadband network access only and do not need to
use a telephone, take the following figure as a reference for connecting the cables.
1
2
3
PO W ER
LAN4 LAN3 LAN2 LAN1USB
RESET
ADSL
1. Telephone jack on the wall 2. Power adapter 3. Computer
If the wireless network function is used on the HG532 for the network
access, you do not need to connect the cables.
4
