Parameter Specifications
Power Specifications Power adapter input: 100 V AC to 240 V AC,
50 Hz to 60 Hz
System power supply: 11 V DC to 14 V DC,
1 A
Power consumption
l Static power consumption: 4 W
l Maximum power consumption: 6.5 W
1.4.2 HG8012H
Introduced the appearance, interfaces, LEDs and device parameters of the HG8012H.
Appearance
Figure 1-7 Appearance of the HG8012H
Port/Button
Figure 1-8 and Figure 1-9 show the ports on the rear panel and side panel of the HG8012H
respectively.
Figure 1-8 Ports and buttons on the rear panel of the HG8012H
EchoLife HG8040H/HG8012H/HG8010H GPON Terminal
Product Description 1 Introduction
Issue 01 (2013-08-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8
