Figure 1-10 Optical ports on the HG8242H
Table 1-9 Description of optical ports on the HG8242H
Port/Button Function
OPTICAL
Indicates an optical port. The optical port is equipped with a
rubber plug and is connected to an optical fiber for upstream
transmission.
The type of the optical connector connected to the OPTICAL
port is SC/APC.
LEDs
Figure 1-11 LEDs on the HG8242H
EchoLife HG8242H/HG8240H/HG8240F/HG8110H GPON
Terminal
Product Description 1 Introduction
