Table 1-10 Indications of the LEDs on the HG8242H
LED Description Status Description
POWER
Power supply
LED
Green: steady on The device is powered on.
Green and red:
steady on
Lithium or NiMH battery power
supply has substituted for the
mains supply.
Off The power supply is cut off.
PON
Authentication
LED
See Table 1-11.
LOS
Connection
LED
See Table 1-11.
LAN1-LAN4
Ethernet port
LED
Steady on
The Ethernet connection is in the
normal state.
Blinking
Data is being transmitted on the
Ethernet port.
Off
The Ethernet connection is not set
up.
TEL1-TEL2
Voice telephone
port LED
Steady on
The HG8242H is registered with
the softswitch but no service flows
are transmitted.
Blinking Service flows are transmitted.
Off
The HG8242H is not powered on
or fails to be registered to the
softswitch.
CATV
CATV port
LED
Steady on
The CATV function is enabled and
CATV signals are received.
Off
The CATV function is disabled or
CATV signals are not received.
Table 1-11 Indications of the PON and LOS LEDs
No.
LED Status
Description
PON LOS
1 Off Off The ONT is disabled by the OLT.
2 Blinks quickly
(twice per
second)
Off The ONT is attempting to set up a
connection to the OLT.
EchoLife HG8242H/HG8240H/HG8240F/HG8110H GPON
Terminal
Product Description 1 Introduction
Issue 01 (2013-08-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
11
