Huawei EchoLife HG8245 Product Description

EchoLife HG8245 GPON Terminal
Product Description 1 Introduction
Figure 1-5 LEDs on the HG8245
Table 1-3 Indications of the LEDs on the HG8245
LED
Description
Status
Description
POWER
Power supply LED
Green: always
on
The device is powered on.
Orange: always
on
The backup battery is supplying
power.
Off
The power supply is cut off.
PON
Authentication LED
See Table 1-4.
LOS
Connection LED
See Table 1-4.
LAN1–LAN4
Ethernet port LED
Always on
The Ethernet connection is in the
normal state.
Blinks
Data is being transmitted on the
Ethernet port.
Off
The Ethernet connection is not set
up.
Issue 01 (2011-01-18) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1-7
