1 Introduction
EchoLife HG8245 GPON Terminal
Product Description
Ports and Buttons on the Side Cover
Figure 1-4 Ports and buttons on the side cover of the HG8245
Table 1-2 Description of ports and buttons on the side cover of the HG8245
Indicates an external backup battery monitoring port, used to
connect to the backup battery unit for battery monitoring.
Indicate USB host ports, used to connect to USB storage
devices.
Indicates the WLAN button, used to enable or disable the
WLAN function.
Indicates the WLAN data encryption switch.
Indicates the reset button. Press the button for a short time to
reset the device; press the button for a long time (longer than
10s) to restore the device to the default settings and reset the
device.
1.4.3 LEDs
1-6 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2011-01-18)
