1.2 Hardware Features
1.2.1 Indicators
Figure 1-2 Indicators on the eircom F2000 eFibre Modem
Table 1-1 Indicators on the eircom F2000 eFibre Modem
Indicator
Status
Description
Power
On
The eircom F2000 is powered on.
Off
The eircom F2000 is powered off or faulty.
DSL
Blinking
The eircom F2000 is being activated through
Ethernet or DSL.
On
The eircom F2000 is activated through Ethernet
or DSL.
Off
The WAN or DSL port is not connected.
Internet
On
The Internet connection is successfully
established but no data is being transmitted.
Blinking
The Internet connection is successfully
established and data is being transmitted.
Off
!
The eircom F2000 is working in bridge mode.
!
No Ethernet or DSL connection is established.
