Assembling the RJ45 Connector (for Network Cables)
The device has adaptive network ports and can connect to the switch using straight-
through or crossover cables. The BTU board of the U1911&U1960&U1981 can also
connect to the peer NT device using straight-through network cables. If you need to
prepare a straight-through or crossover cable, strip off the jacket of the twisted-pair
cable, insert the core wires into the eight-pin feet of a RJ45 connector according to the
pin assignment described in the following table, and use a crimping tool to crimp the
connector.
Crossover cable pin assignment
Connector 1 (T568A Standard) Connector 2 (T568B Standard)
Pin Foot Color Pin Foot Color
1 White and green 1 White and orange
2 Green 2 Orange
3 White and orange 3 White and green
4 Blue 4 Blue
5 White and blue 5 White and blue
6 Orange 6 Green
7 White and brown 7 White and brown
8 Brown 8 Brown
Straight-through network cable pin assignment
Connector 1 (T568B Standard) Connector 2 (T568B Standard)
Pin Foot Color Pin Foot Color
1 White and orange 1 White and orange
2 Orange 2 Orange
3 White and green 3 White and green
4 Blue 4 Blue
5 White and blue 5 White and blue
6 Green 6 Green
7 White and brown 7 White and brown
8 Brown 8 Brown
1 8
RJ45
