15
2
Connecting Cabinet Input Power Cables
Input Power Cables
to the PDU (02116410)
Input Power Cables
to the PDU (02116411 & 02116412)
3
Connecting PDU2000 Power Cables
Full-height Vertical
Non-intelligent PDU2000 (02116410)
Power Cables to a Horizontal
Non-intelligent PDU2000 (02116411 & 02116412)
If the cabinet is equipped with an
intelligent PDU2000, refer to the cable
connections for a horizontal non-intelligent
PDU2000.
To Next Page
