2 Connecting Cables
If you have subscribed to digital subscriber line (DSL) broadband, you can connect
the HG552e to a telephone port for Internet access.
Follow the steps in the following figure to connect devices properly.
When configuring the HG552e for the first time, use an Ethernet cable to
connect the HG552e to a computer.
1 Telephone wall jack 2 Splitter 3 Telephone
4 Computer 5 Set-top box 6 HG552e
7 Power adapter
a MODEM port b PHONE port c LINE port
USB
On/Off
1
2
3
4
53
6
7
a
c
b
