Huawei HG655b User Manual

HUAWEI HG655b Home Gateway
User Guide
Appendix
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9-1
9 Appendix
9.1 Default Settings
Parameter Setting
IP address of the LAN interface 192.168.1.1
Subnet mask of the LAN interface 255.255.255.0
User name / Password u
Web-based configuratio
sed for logging in to the
n utility
admin
admin /
DHCP server function Enable
9 echnical Specificat.2 T ions
Item Specification
Entire-device power supply 12 V DC, 1.5 A
Entire-device power consumption < 16 W
Ambient temperature for operation
0°C to 40°C (32
℉
to 104
℉
)
Relative humidity for operation 5% to 95%, non-condensing
Dimensions (L × W × H) × 60 mm × 165 mm 194 mm
Weight <1 kg
ADSL standards
z
ITU G.992.1 (G.dmt) Annex A
z
ITU G.994.1 (G.hs), ANSI T1.413 Issue 2
ADSL2 standard ITU G.992.3 (G.dmt.bis) Annex A
ADSL2+ standard ITU G.992.5 Annex A
Standards
standard VDSL2 ITU G.993.2 Annex B, ITU G.994.1
G.dmt
T1.413
z
Maximum downlink rate: 8 Mbit/s
z
Maximum uplink rate: 896 kbit/s
G.992.5 (ADSL2+)
z
Maximum downlink rate: 24 Mbit/s
z
Maximum uplink rate: 1024 kbit/s
DSL
transmission
rates
G.993.2 (VDSL2)
z
Maximum uplink rate: 45 Mbit/s
z
Maximum downlink rate: 88 Mbit/s

Huawei HG655b Specifications

General

Brand	Huawei
Model	HG655b
Category	Gateway
Language	English
