3.2
Connecting the Cables
Before connecting the cables, power off all equipment connected to it
including the HG655d, the PC, and the switch.
Figure 3-1 Cable connection
1 Phone jack on the wall 2 Splitter 3 Telephone
4 Set-top box 5 PC 6 Power adapter
3.3
Getting Started
To power on the HG655d, press the ON/OFF button on the rear panel of the HG655d.
After you power on the HG655d, the DSL indicator blinks (for less than three minutes),
which indicates that the HG655d is being activated. Later, the DSL indicator turns solid
on. The POWER indicator is also solid on, which indicates that the HG655d is working
properly.
10
