c. Secure the legs to the concrete platforms.
Model
Block Width (W1)
Block
Depth
(D1)
Block
Height
(H)
Center
Distance
(W2)
Center
Distance (D2)
NetCol500
-A060
W1 ≥ 250
D1 ≥ 250
150
–250
944
1064
NetCol500
-A080
W1 ≥ 250
D1 ≥ 250
150
–250
944
1894
NetCol500
-A120
W1 ≥ 250
D1 ≥ 250
150
–250
2038
1064
Concrete platform dimensions (unit: mm)
NetCol500-A110
Unit: mm
The strength level of
the concrete platform
must be equal to or
greater than C20.
Securing the legs to the concrete platforms
